High performance
Vena® Sil Turbo
Silicone turbo hose for turbocharger and intercooler systems
Product
Vena® Sil Turbo
Silicone turbo hose for turbocharger and intercooler systems due to its high capacity to withstand hydrocarbons and oil particles in the pressurized air.
- Temperature
- -55°C / +200°C (-67°F / +392°F) Open TD to check a working temperature against the range.
- Quality
-
- The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.
- Manufacturing Length
- 4 meters long (13.12 ft.)
Properties
From the outside in
01
Outer layer
Silicone VMQ , smooth with convultions and red.
02
Reinforcement
Aramid fabrics.
03
Inner layer
Fluorosilicone FVMQ.
- Applications
-
Recommended for its use in straight sections for turbocharger systems in:
BusesCoachesLorriesIndustrial vehiclesMarine engines
Check a working temperature
200°C
Within rangeContinuous service
- Quality
-
- The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.
- Temperature
- -55°C / +200°C (-67°F / +392°F)
- Reference
- DO 03.10 FT 031 Rev 05 TURBOLOADER.pdf
